Light source: Beam end: 10 x 60W RGBW LED
Strobe end: 96 x 3W CW LED
96 x 3W WW LED
96 x 0.5W RGB LED
White light color temperature: 6,300K
Luminous flux: 22,400 lm
LED life expectancy: 20,000 hours
Optical system
Zoom angle: Beam angle: 2.8°-31° (beam end)
Spot angle: 5°-46° (beam end)
controls and procedures
Control panel: 1.77mm display
Control protocol: DMX512, RDM
DMX channel mode: 5 types
Channel mode: 17/27/99/108/168 channels
Software Upgrade: Update software via DMX connection
X-axis/Y-axis
Y-axis operating angle: 202°
Fixed lock: vertical lock
Electrical and interface
Input power: 180-240V~ 50/60Hz
Power: 1000W
Power Outlet: Power Connector In/Out
Signal input/output: three-pin or five-pin XLR socket
