Input voltage: AC100-240V, 50/60Hz
Quota power: 1150W
Light source: 1000W LED module
LED life: 20,000 hours
Color temperature: 6500K
Caliber: 150mm
Color rendering index: standard mode Ra>75, high display mode Ra>90
Luminous flux: 32000LM
Signal interface: three-core XLR/five-core XLR optional
Control mode: DMX512, RDM, self-propelled, master-slave, voice control
Channel mode: 36 international standard DMX512 channels
Display system: 2.8-inch touch LCD display, Chinese and English display, 180-degree rotation
Fixed colors: 6 colors + white light
Color mixing system: independent CMY color mixing system
Color temperature adjustment: independent CTO 2800K-6500K linear adjustment
Prism disk: rotating 3 prisms + 6 rows of mirrors
Effect wheel: Stunning simulation of dynamic flames, gurgling water and other dynamic effects
Fixed pattern: 11 plug-in fixed pattern pieces with outer diameter 25.4mm + white circle
Rotating pattern: 7 pattern pieces (pluggable) outer diameter 26.9mm, effective diameter 16.5mm, thickness 1.1mm
Cutting system: 4 independent cutting blades, each blade can be individually closed and rotated 90°
Atomization system: 0~100% linear atomization
Aperture system: 6%~100% smooth adjustment
Zoom system: 5.5°~60° linear zoom
Dimming system: 0-100% linear adjustment
Strobe system: The frequency can reach up to 25Hz, and random strobe and pulse strobe can be selected. Horizontal scan: 540° (16 bit precision scan)
Vertical scanning: 270° (16 bit precision scanning)
XY: Using five-phase motor with magnetic encoding positioning function
Protection level: IP20
Working environment: 0-45℃
Product size: 510L*345W*800H(mm)
Carton size: 730*690*590 (mm)
Product net weight: 43KG
Product gross weight: 51.5KG
